AMI BEARINGS UEFBL204W
#UEFBL204W
On request
Flange-Mount Ball Bearing Unit - Three-Bolt Bracket Style, 20 mm Bore, PBT Thermoplastic Housing, Standard Duty, Accu-Loc Locking, Contact with Flinger
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | AMI BEARINGS |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 20 mm |
| Horizontal bolt spacing | 38.1 mm |
| Bore type | Round |
| Vertical bolt spacing | 22.2 mm |
| Duty type | Standard Duty |
| Shaft centerline height | 42.9 mm |
| Mounting type | Three-Bolt Bracket Style |
| Hub diameter | 63.5 mm |
| Housing material | PBT Thermoplastic |
| Bracket width | 62 mm |
| Locking device | Accu-Loc |
| Unit standoff | 35.7 mm |
| Radial dynamic load capacity | 1310 kgf |
| Bolt size | M10 |
| Radial static load capacity | 680 kgf |
| Lubrication type | Lubrication Fitting |
| Seal type | Contact with Flinger |
| Series | UEFBL200W |
| Length through bore | 33 mm |
| Replacement bearing | UE204 |
