AMI BEARINGS UEFK206NP
#UEFK206NP
On request
Flange-Mount Ball Bearing Unit - Three-Bolt Bracket Style, 30 mm Bore, Cast Iron - Nickel Protection Housing, Standard Duty, Accu-Loc Locking, Contact with Flinger
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | AMI BEARINGS |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 30 mm |
| Horizontal bolt spacing | 40 mm |
| Bore type | Round |
| Vertical bolt spacing | 29 mm |
| Duty type | Standard Duty |
| Shaft centerline height | 50 mm |
| Mounting type | Three-Bolt Bracket Style |
| Hub diameter | 78 mm |
| Housing material | Cast Iron - Nickel Protection |
| Bracket width | 65 mm |
| Locking device | Accu-Loc |
| Unit standoff | 41.9 mm |
| Radial dynamic load capacity | 2000 kgf |
| Bolt size | M8 |
| Radial static load capacity | 1150 kgf |
| Lubrication type | Lubrication Fitting |
| Seal type | Contact with Flinger |
| Series | UEFK200NP |
| Length through bore | 39.8 mm |
| Replacement bearing | UE206 |
