AMI BEARINGS KHPF206-18
#KHPF206-18
On request
Flange-Mount Ball Bearing Unit - Three-Bolt Flange, 1.1250 in Bore, Pressed Steel Housing, Standard Duty, Eccentric Collar Locking, Contact Seal
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | AMI BEARINGS |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 1.125 in |
| Radial dynamic load capacity | 4410 lbf |
| Bolt circle diameter | 3.5625 in |
| Radial static load capacity | 2540 lbf |
| Overall length/diameter | 4.4375 in |
| Seal type | Contact Seal |
| Bore type | Round |
| Length through bore | 1-13/32 ft |
| Duty type | Standard Duty |
| Lubrication type | Cannot Be Relubricated |
| Mounting type | Three-Bolt Flange |
| Series | KHPF200 |
| Housing material | Pressed Steel |
| Replacement bearing | KH206-18 |
| Locking device | Eccentric Collar |
