AMI BEARINGS UEF211NP
#UEF211NP
On request
Flange-Mount Ball Bearing Unit - Four-Bolt Flange, 55 mm Bore, Cast Iron - Nickel Protection Housing, Standard Duty, Accu-Loc Locking, Contact with Flinger
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | AMI BEARINGS |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 55 mm |
| Radial dynamic load capacity | 4400 kgf |
| Bolt center-to-center length | 130 mm |
| Radial static load capacity | 3000 kgf |
| Bore type | Round |
| Seal type | Contact with Flinger |
| Duty type | Standard Duty |
| Length through bore | 56.6 mm |
| Mounting type | Four-Bolt Flange |
| Lubrication type | Lubrication Fitting |
| Housing material | Cast Iron - Nickel Protection |
| Series | UEF200NP |
| Locking device | Accu-Loc |
| Replacement bearing | UE211 |
| Expansion type | Non-Expansion Bearing (Fixed) |
