AMI BEARINGS UKPX20+HA2320

Name: AMI BEARINGS UKPX20+HA2320
Brand: AMI BEARINGS
SKU: UKPX20+HA2320

#UKPX20+HA2320 On request

Category PILLOW BLOCK BALL BEARING UNITS

Part Number UKPX20+HA2320

UKPX20+HA2320 3-7/16 PILLOW BLOCK

Manufacturer description

Pillow Block Ball Bearing Unit - Two-Bolt Base, 3.4375 in Bore, Cast Iron Material, Medium Duty, Non-Expansion Bearing (Fixed)

Price on request — a consultant will confirm lead time and terms.

Talk to a technical consultant

Specifications

Brand	AMI BEARINGS
Category	PILLOW BLOCK BALL BEARING UNITS
Mounting	Two-Bolt Base
Overall width	4-3/4 in
Bore diameter	3.4375 in
Radial dynamic load capacity	30200 lbf
Bore type	Round
Radial static load capacity	23600 lbf
Base to bore centerline	5 in
Base width	4-3/4 in
Duty type	Medium Duty
Bolt center-to-center length	11-3/4 to 14-3/4 ft
Housing material	Cast Iron
Bolt size	1
Locking device	Adapter Mounted
Lubrication type	Lubrication Fitting
Seal type	Contact with Slinger
Series	UKPX00+HA2000
Expansion type	Non-Expansion Bearing (Fixed)
Replacement bearing	UKX20+HA2320
Overall length	17 in
Manufacturer product page	http://catalog.amibearings.com/item/adapter-sleeve-locking/r-sleeve-locking-pillow-block-unit-ukpx00-h-series/ukpx20-ha2320
Overall height	10 in
