AMI BEARINGS BTM203
#BTM203
On request
Flange-Mount Ball Bearing Unit - Three-Bolt Flange, 17 mm Bore, Malleable Iron Housing, Standard Duty, Set Screw Locking, Contact Seal
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | AMI BEARINGS |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 17 mm |
| Radial dynamic load capacity | 975 kgf |
| Bolt circle diameter | 63.5 mm |
| Radial static load capacity | 490 kgf |
| Overall length/diameter | 81 mm |
| Seal type | Contact Seal |
| Bore type | Round |
| Length through bore | 22 mm |
| Duty type | Standard Duty |
| Lubrication type | Lubrication Fitting |
| Mounting type | Three-Bolt Flange |
| Series | BTM200 |
| Housing material | Malleable Iron |
| Replacement bearing | B3 |
| Locking device | Set Screw |
