AMI BEARINGS UEFBL204-12B
#UEFBL204-12B
On request
Flange-Mount Ball Bearing Unit - Three-Bolt Bracket Style, 0.7500 in Bore, PBT Thermoplastic Housing, Standard Duty, Accu-Loc Locking, Contact with Flinger
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | AMI BEARINGS |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 0.75 in |
| Horizontal bolt spacing | 1-1/2 in |
| Bore type | Round |
| Vertical bolt spacing | 7/8 in |
| Duty type | Standard Duty |
| Shaft centerline height | 1-11/16 in |
| Mounting type | Three-Bolt Bracket Style |
| Hub diameter | 2-1/2 in |
| Housing material | PBT Thermoplastic |
| Bracket width | 2-7/16 in |
| Locking device | Accu-Loc |
| Unit standoff | 1-13/32 in |
| Radial dynamic load capacity | 2890 lbf |
| Bolt size | 3/8 |
| Radial static load capacity | 1500 lbf |
| Lubrication type | Lubrication Fitting |
| Seal type | Contact with Flinger |
| Series | UEFBL200B |
| Length through bore | 1-19/64 in |
| Replacement bearing | UE204-12 |
