AMI BEARINGS UK212+H2312
#UK212+H2312
On request
Ball Insert Bearing - Tapered 1:12 Bore, 55 mm ID, 110 mm OD, 62 mm Width, Adapter Mount
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | AMI BEARINGS |
| Category | BALL INSERT BEARINGS |
| Bore diameter | 55 mm |
| Radial dynamic load capacity | 5350 kgf |
| Outside diameter | 110 mm |
| Radial static load capacity | 3700 kgf |
| Outer ring width | 26 mm |
| Bearing material | AISI 52100 Steel |
| Inner ring width | 62 mm |
| Seal type | Contact with Slinger |
| Bore type | Tapered 1:12 |
| Series | UK200+H2000 |
| Locking device | Adapter Mount |
| Manufacturer product page | http://catalog.amibearings.com/item/normal-duty-adapter-sleeve-bearing-insert/apter-sleeve-locking-bearing-insert-uk200-h-series/uk212-h2312 |
