AMI BEARINGS UEFPL205-16CW
#UEFPL205-16CW
On request
Flange-Mount Ball Bearing Unit - Four-Bolt Flange, 1.0000 in Bore, PBT Thermoplastic Housing, Standard Duty, Accu-Loc Locking, Contact with Flinger
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | AMI BEARINGS |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 1 in |
| Radial dynamic load capacity | 3150 lbf |
| Bolt center-to-center length | 2.75 in |
| Radial static load capacity | 1780 lbf |
| Bore type | Round |
| Seal type | Contact with Flinger |
| Duty type | Standard Duty |
| End type | Open |
| Mounting type | Four-Bolt Flange |
| Length through bore | 1-25/64 in |
| Housing material | PBT Thermoplastic |
| Lubrication type | Lubrication Fitting |
| Locking device | Accu-Loc |
| Series | UEFPL200CW |
| Expansion type | Non-Expansion Bearing (Fixed) |
| Replacement bearing | UE205-16 |
