AMI BEARINGS UKPU309+HE2309

Name: AMI BEARINGS UKPU309+HE2309
Brand: AMI BEARINGS
SKU: UKPU309+HE2309

#UKPU309+HE2309 On request

Category PILLOW BLOCK BALL BEARING UNITS

Part Number UKPU309+HE2309

UKPU309+HE2309 1-1/2 PILLOW BLOCK

Manufacturer description

Pillow Block Ball Bearing Unit - Two-Bolt Base, 1.5000 in Bore, Cast Iron Material, Heavy Duty, Non-Expansion Bearing (Fixed)

Price on request — a consultant will confirm lead time and terms.

Talk to a technical consultant

Specifications

Brand	AMI BEARINGS
Category	PILLOW BLOCK BALL BEARING UNITS
Mounting	Two-Bolt Base
Overall width	3 in
Bore diameter	1.5 in
Radial dynamic load capacity	11570 lbf
Bore type	Round
Radial static load capacity	6630 lbf
Base to bore centerline	2.875 in
Base width	3 in
Duty type	Heavy Duty
Bolt center-to-center length	7-5/8 to 8-7/8 ft
Housing material	Cast Iron
Bolt size	9/16
Locking device	Adapter Mounted
Lubrication type	Lubrication Fitting
Seal type	Contact with Slinger
Series	UKPU300+HE2000
Expansion type	Non-Expansion Bearing (Fixed)
Replacement bearing	UK309+HE2309
Overall length	10.25 in
Manufacturer product page	http://catalog.amibearings.com/item/adapter-sleeve-locking/-sleeve-locking-pillow-block-unit-ukpu300-h-series/ukpu309-he2309
Overall height	5.625 in
