AMI BEARINGS MUCFBL207-20RFW
#MUCFBL207-20RFW
On request
Flange-Mount Ball Bearing Unit - Three-Bolt Bracket Style, 1.2500 in Bore, PBT Thermoplastic Housing, Standard Duty, Set Screw Locking, Dual Lip with Slinger
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | AMI BEARINGS |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 1.25 in |
| Horizontal bolt spacing | 2 in |
| Bore type | Round |
| Vertical bolt spacing | 1-1/4 in |
| Duty type | Standard Duty |
| Shaft centerline height | 2-3/8 in |
| Mounting type | Three-Bolt Bracket Style |
| Hub diameter | 3-3/4 in |
| Housing material | PBT Thermoplastic |
| Bracket width | 3-1/2 in |
| Locking device | Set Screw |
| Unit standoff | 1-55/64 in |
| Radial dynamic load capacity | 4950 lbf |
| Bolt size | 1/2 |
| Radial static load capacity | 2770 lbf |
| Lubrication type | Lubrication Fitting |
| Seal type | Dual Lip with Slinger |
| Series | MUCFBL200RFW |
| Length through bore | 1.689 in |
| Replacement bearing | MUC207-20RF |
