AMI BEARINGS MUCFK203NP
#MUCFK203NP
On request
Flange-Mount Ball Bearing Unit - Three-Bolt Bracket Style, 17 mm Bore, Cast Iron - Nickel Protection Housing, Standard Duty, Set Screw Locking, Contact with Flinger
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | AMI BEARINGS |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 17 mm |
| Horizontal bolt spacing | 32 mm |
| Bore type | Round |
| Vertical bolt spacing | 27 mm |
| Duty type | Standard Duty |
| Shaft centerline height | 42 mm |
| Mounting type | Three-Bolt Bracket Style |
| Hub diameter | 62 mm |
| Housing material | Cast Iron - Nickel Protection |
| Bracket width | 52 mm |
| Locking device | Set Screw |
| Unit standoff | 33.3 mm |
| Radial dynamic load capacity | 1110 kgf |
| Bolt size | M8 |
| Radial static load capacity | 540 kgf |
| Lubrication type | Lubrication Fitting |
| Seal type | Contact with Flinger |
| Series | MUCFK200NP |
| Length through bore | 31 mm |
| Replacement bearing | MUC203 |
