AMI BEARINGS UKFC210+H2310
#UKFC210+H2310
On request
Flange-Mount Ball Bearing Unit - Four-Bolt Piloted, 45 mm Bore, Cast Iron Housing, Standard Duty, Adapter Sleeve Locking, Contact with Flinger
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | AMI BEARINGS |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 45 mm |
| Radial static load capacity | 2370 kgf |
| Bolt circle diameter | 138 mm |
| Seal type | Contact with Flinger |
| Overall length/diameter | 165 mm |
| Length through bore | 55 mm |
| Bore type | Round |
| Pilot diameter | 110 mm |
| Duty type | Standard Duty |
| Unit standoff | 37.5 mm |
| Mounting type | Four-Bolt Piloted |
| Bolt size | M14 |
| Housing material | Cast Iron |
| Lubrication type | Lubrication Fitting |
| Locking device | Adapter Sleeve |
| Series | UKFC200+H2000 |
| Radial dynamic load capacity | 3600 kgf |
| Replacement bearing | UK210+H2310 |
