AMI BEARINGS MUCFBL205CEW
#MUCFBL205CEW
On request
Flange-Mount Ball Bearing Unit - Three-Bolt Bracket Style, 25 mm Bore, PBT Thermoplastic Housing, Standard Duty, Set Screw Locking, Contact with Flinger
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | AMI BEARINGS |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 25 mm |
| Horizontal bolt spacing | 41.3 mm |
| Bore type | Round |
| Vertical bolt spacing | 28.6 mm |
| Duty type | Standard Duty |
| Shaft centerline height | 46 mm |
| Mounting type | Three-Bolt Bracket Style |
| Hub diameter | 70 mm |
| Housing material | PBT Thermoplastic |
| Bracket width | 63.5 mm |
| Locking device | Set Screw |
| Unit standoff | 55.1 mm |
| Radial dynamic load capacity | 1220 kgf |
| Bolt size | M10 |
| Radial static load capacity | 640 kgf |
| Lubrication type | Lubrication Fitting |
| Seal type | Contact with Flinger |
| Series | MUCFBL200CEW |
| End type | Closed |
| Replacement bearing | MUC205 |
| Length through bore | 34 mm |
