BALDOR-RELIANCE EM7114T-C
#EM7114T-C
On request
Explosion Proof / Hazardous Location Motor - 3 ph, 1 hp, 1800 rpm, 190/380//230/460 V, 143T Frame, XPFC (Explosion Proof Fan Cooled) Enclosure, 50/60 Hz
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | BALDOR-RELIANCE |
| Category | EXPLOSION PROOF (HAZARDOUS LOCATION) MOTORS |
| Motor category | General Purpose Motor |
| Overall length (c-dimension) | 16.28 in |
| Motor phase | 3 ph |
| Service factor | 1.00 |
| Motor horsepower | 1.00 , 1 hp |
| Frame material | Cast Iron |
| Synchronous rpm | 1800 rpm |
| Insulation class | B |
| Motor supply voltage | 190/380//230/460 V |
| Standards met | UL, UR, CSA |
| Frame size | 143T |
| Temperature code | T4 |
| Enclosure type | XPFC (Explosion Proof Fan Cooled) |
| Group & class | Division 1, lass I - roup & D, lass II - roup F & C, G |
| Frequency rating | 50/60 Hz |
| Harmonization code | 8501.51.6040 |
| Duty / condition type | Continuous Duty |
| Weight | 78 lbs |
| Mounting type | Footed |
| Applications | Ideal for use on pumps, fans, and conveyors where hazardous fumes and dust are present requiring Div 1 UL listed and/or CSA approved enclosures. |
| Base rpm | 1750 rpm |
| Additional details | UL & CSA approved for Class I, Group D; Class I, Group D, Class II, Group F & G; Class I, Group C & D, Class II, Group F & G. Totally enclosed heavy gauge steel and cast iron construction. Corrosion resistant epoxy paint. Single or Three Phase designs. 1.0 Service Factor. Three Phase 143T frame and larger have 60Hz & 50Hz data included on the nameplate. Super-E® explosion proof motors have NEMA Premium® efficiency and 3 year warranty. Fixed speed sine wave operation only. |
| Full load amps | 3 / 1.5 / 3 / 1.4 A |
| Manufacturer catalog | http://www.baldor.com/mvc/DownloadCenter/Files/CA501 |
| Full load efficiency | 0.855 |
| Manufacturer product page | http://www.baldor.com/catalog/EM7114T-C |
| Amps @ voltage | 3.1 @ 208 ; 3.0 @ 230 ; 3.0 @ 190 ; 1.5 @ 460 ; 1.4 @ 380 A, A, A, A, A, V |
| Wiring diagram | https://www.baldorvip.com/servlet/productInfoPacket?nameplate=X&layoutdiagram=X&electrical=X&connectiondiagram=X&language=E&matnr=EM7114T-C&vkorg=BEC |
| Volts @ frequency | 190 @ 50 ; 380 @ 50 ; 230 @ 60 ; 460 @ 60 V, V, V, V, Hz |
| Instructional video | https://youtu.be/j-mFjRPjiFU?list=PLUJtYxZcxl_oZa19yqrOGvU3YxQu5APRV |
| Shaft diameter | 0.88 in |
