BALDOR-RELIANCE GLF4032BG
#GLF4032BG
On request
Right Angle Worm Gear Speed Reducer - Single Reduction, 40:1 Ratio, 3.25 in Center Distance, C-Face Coupling, 0.8800 in Input Size, Left Hand Output, 140TC Frame
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | BALDOR-RELIANCE |
| Category | RIGHT ANGLE WORM GEAR SPEED REDUCERS |
| Reduction | Single |
| Maximum output rpm | 44.000 @ 1750 input rpm |
| Center distance | 3.25 in |
| Maximum output torque | 2374 in-lbs |
| Maximum input horsepower | 2.200 @ 1750 hp, rpm |
| Housing material | Cast Iron |
| Ratio | 40:1 |
| Overhung load capacity | 1500 lb |
| Output direction | Left Hand |
| Housing dimensions | 8.92 x 7-1/4 x 11.04 in |
| Manufacturer reducer size | 932 |
| Housing height | 11.04 in |
| Input type | C-Face Coupling |
| Housing length | 11.04 in |
| Input size | 0.88 in |
| Housing width | 7.25 in |
| Output type | Solid Shaft |
| Mounting type | Basic Gear Reducer Drive |
| Output size | 1.375 in |
| Includes | Klubersynth UHI-6-460 Synthetic Oil |
| Nema / iec frame size | 140TC |
