BALDOR-RELIANCE KL1200
#KL1200
On request
General Purpose Motor - 1 ph, 1/6 hp, 1800 rpm, 115/230 V, 56C Frame, ODP (Open Drip-Proof) Enclosure, 60 Hz, Footless/C-Face Flange Mount
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
BALDOR-RELIANCE — BALDOR-RELIANCE KL1200
- Pressure cast aluminum end plates with ribbed design for rigidity
- Ball bearings with a locked drive end bearing, heavy-gauge steel frame
- Applications: Pumps, fans, conveyors, machine tools, gear reducers and other applications requiring a NEMA C-face motor
Specifications
| Brand | BALDOR-RELIANCE |
| Category | GENERAL PURPOSE MOTORS |
| Motor phase | 1 ph |
| Bearing type | Ball |
| Motor horsepower | 0.17 , 1/6 hp |
| Nema design class | N |
| Synchronous rpm | 1800 rpm |
| Service factor | 1.35 |
| Motor supply voltage | 115/230 V |
| Frame material | Steel |
| Frame size | 56C |
| Insulation class | B |
| Enclosure type | ODP (Open Drip-Proof) |
| Ip rating | 22/23 |
| Frequency rating | 60 Hz |
| Standards met | UR, CSA |
| Mounting type | Footless/C-Face Flange |
| Weight | 19 lbs |
| Duty / condition type | Continuous Duty |
| Applications | Pumps, fans, conveyors, machine tools, gear reducers and other applications requiring a NEMA C-face motor. |
| Full load current | 1.9 A |
| Additional details | Pressure cast aluminum end plates with ribbed design for rigidity. Ball bearings with a locked drive end bearing, heavy-gauge steel frame. |
| Full load efficiency | 0.49 |
| Harmonization code | 8501.40.4040 |
| Amps @ voltage | 3.8 A @ 115 ; 2.3 A @ 208 ; 1.9 A @ 230 V |
| Manufacturer catalog | http://www.baldor.com/mvc/DownloadCenter/Files/CA501 |
| Volts @ frequency | 115 V @ 60 ; 230 V @ 60 Hz |
| Manufacturer product page | http://www.baldor.com/catalog/KL1200 |
| Shaft diameter | 0.63 in |
| Wiring diagram | https://www.baldorvip.com/servlet/productInfoPacket?nameplate=X&layoutdiagram=X&electrical=X&connectiondiagram=X&language=E&matnr=KL1200&vkorg=BEC |
| Overall length (c-dimension) | 11.22 in |
| Instructional video | https://youtu.be/j-mFjRPjiFU?list=PLUJtYxZcxl_oZa19yqrOGvU3YxQu5APRV |
| Warranty | 2 Year Warranty |
