BROWNING VF2S-210

Name: BROWNING VF2S-210
Brand: BROWNING
SKU: VF2S-210

#VF2S-210 On request

Brand BROWNING

Category FLANGE-MOUNT BALL BEARING UNITS

Part Number VF2S-210

767400

Manufacturer description

767400 Flange-Mount Ball Bearing Unit - Two-Bolt Flange, 0.6250 in Bore, Cast Iron Housing, Standard Duty, Set Screw Locking, Single Lip Contact with Flinger

Price on request — a consultant will confirm lead time and terms.

Need to confirm compatibility?

Talk to a technical consultant

Call

BROWNING — BROWNING VF2S-210

With Seal Flinger

Specifications

Brand	BROWNING
Category	FLANGE-MOUNT BALL BEARING UNITS
Bore diameter	0.625 in
Radial static load capacity	1117 lb
Bolt center-to-center length	3 in
Seal type	Single Lip Contact with Flinger
Overall length/diameter	3.875 in
Length through bore	1.0313 in
Overall height	1.0781 in
Maximum operating temperature	200 °F
Bore type	Round
Finish/coating	Gray Painted
Duty type	Standard Duty
Bolt size	0.375 in
Mounting type	Two-Bolt Flange
Maximum rpm	7500 RPM
Housing material	Cast Iron
Lubrication type	Lubrication Fitting
Locking device	Set Screw
Series	VF2S 200
Expansion type	Non-Expansion Bearing (Fixed)
Application	Browning - Standard
Housing width	0.375 in
Replacement bearing	VS-210
Overall width	2.125 in
Manufacturer catalog number	767400
Inner ring width	1.0313 in
Bearing material	52100 Bearing Steel
Cad drawing	https://www.3dcontentcentral.com/PremiumSSS-Download-Model.aspx?catalogId=12261&id=1650
Radial dynamic load capacity	2108 lb
Manufacturer upc number	662289521258
