BROWNING PBE920FX3
#PBE920FX3
On request
730052
Manufacturer descriptionPillow Block Roller Bearing Unit - 3.0000 in Bore Dia., Four-Bolt Base, Solid Pillow Block, Cast Iron Material, Non-Expansion Bearing (Fixed)
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
BROWNING — BROWNING PBE920FX3
- With Seal Flinger
Specifications
| Brand | BROWNING |
| Category | PILLOW BLOCK ROLLER BEARING UNITS |
| Bore diameter | 3 in |
| Finish/coating | Gray Painted |
| Overall length | 12 in |
| Overall width | 4-1/2 in |
| Overall height | 6.25 in |
| Seal type | Contact Seal |
| Mounting | Four-Bolt Base |
| Radial dynamic load capacity | 9630 lbs |
| Bearing type | Tapered Roller |
| Maximum operating temperature | 200 °F |
| Bore type | Round |
| Maximum rpm | 1000 RPM |
| Housing construction | Solid Pillow Block |
| Lubrication type | Lubrication Fitting |
| Base to bore centerline | 3.125 in |
| Bolt size | 5/8 in |
| Duty type | Heavy Duty |
| Series | PBE920 |
| Housing material | Cast Iron |
| Standards met | ABMA, ISO |
| Locking device | Double Set Screw |
| Bolt center-to-center length | 8.0000 to 9.8750 in |
| Manufacturer catalog number | 730052 |
| Base width | 4 in |
| Cad drawing | https://www.3dcontentcentral.com/PremiumSSS-Download-Model.aspx?catalogId=12261&id=7172 |
| Expansion type | Non-Expansion Bearing (Fixed) |
