BROWNING VF2S-122
#VF2S-122
On request
767617
Manufacturer description767617 Flange-Mount Ball Bearing Unit - Two-Bolt Flange, 1.3750 in Bore, Cast Iron Housing, Intermediate Duty, Set Screw Locking, Single Lip Contact
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
BROWNING — BROWNING VF2S-122
- Without Seal Flinger
Specifications
| Brand | BROWNING |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 1.375 in |
| Radial static load capacity | 3493 lb |
| Bolt center-to-center length | 5.125 in |
| Seal type | Single Lip Contact |
| Overall length/diameter | 6.125 in |
| Length through bore | 1.2813 in |
| Overall height | 1.6094 in |
| Maximum operating temperature | 200 °F |
| Bore type | Round |
| Finish/coating | Gray Painted |
| Duty type | Intermediate Duty |
| Bolt size | 0.5 in |
| Mounting type | Two-Bolt Flange |
| Maximum rpm | 2500 RPM |
| Housing material | Cast Iron |
| Lubrication type | Lubrication Fitting |
| Locking device | Set Screw |
| Series | VF2S 100 |
| Expansion type | Non-Expansion Bearing (Fixed) |
| Application | Browning - Standard |
| Housing width | 0.5938 in |
| Replacement bearing | VS-122 |
| Overall width | 3.625 in |
| Manufacturer catalog number | 767617 |
| Inner ring width | 1.2813 in |
| Bearing material | 52100 Bearing Steel |
| Cad drawing | https://www.3dcontentcentral.com/PremiumSSS-Download-Model.aspx?catalogId=12261&id=1638 |
| Radial dynamic load capacity | 5782 lb |
| Manufacturer upc number | 662289521210 |
