BROWNING VTBS-218
#VTBS-218
On request
767813
Manufacturer description767813 Pillow Block Ball Bearing Unit - Tapped Base, 1.1250 in Bore, Cast Iron Material, Normal Duty, Non-Expansion Bearing (Fixed)
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
BROWNING — BROWNING VTBS-218
- With Seal Flinger
Specifications
| Brand | BROWNING |
| Category | PILLOW BLOCK BALL BEARING UNITS |
| Mounting | Tapped Base |
| Radial dynamic load capacity | 4381 lb |
| Bore diameter | 1.125 in |
| Radial static load capacity | 2567 lb |
| Bore type | Round |
| Base width | 1.5 in |
| Base to bore centerline | 1.6875 in |
| Bolt center-to-center length | 3 in |
| Duty type | Normal Duty |
| Maximum rpm | 4500 RPM |
| Housing material | Cast Iron |
| Tapping depth | 5/8 in |
| Locking device | Set Screw |
| Tap thread size | 41836 |
| Seal type | Single Lip Contact with Flinger |
| Lubrication type | Lubrication Fitting |
| Expansion type | Non-Expansion Bearing (Fixed) |
| Series | VTBS |
| Overall length | 4 in |
| Replacement bearing | VS-218 |
| Overall height | 3.375 in |
| Manufacturer catalog number | 767813 |
| Finish/coating | Grey Painted |
| Insert material | 52100 Bearing Steel |
| Cad drawing | https://www.3dcontentcentral.com/PremiumSSS-Download-Model.aspx?catalogId=12261&id=1263 |
| Maximum operating temperature | 200 °F |
| Manufacturer upc number | 662289530168 |
