DICHTOMATIK AMERICAS 12X18X3VZ
#12X18X3VZ
On request
0.472X0.709X0.118 VZ Metric Oil Seal - 12 mm Shaft, 18 mm OD, 3 mm Width, Nitrile Rubber Lip Material
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
DICHTOMATIK AMERICAS — DICHTOMATIK AMERICAS 12X18X3VZ
- Single lip without a garter spring
- Precision ground OD with Rubber covered top face
Specifications
| Brand | DICHTOMATIK AMERICAS |
| Category | OIL SEALS |
| Shaft diameter | 12 mm |
| Construction description | Single lip without a garter spring. Precision ground OD with rubber covered top face |
| Outside diameter | 18 mm |
| Typical application | Pumps, Transmissions, Gearboxes, Axles, Other industrial uses |
| Width | 3 mm |
| Synonym | Radial Shaft Seal;Oil Seal;Grease Seal;Lip Seal |
| Lip material | Nitrile Rubber |
| Harmonization code | 4016.93.5020 US |
| Seal type | Single Lip without a Garter Spring |
| Manufacturer catalog number | 12X18X3VZ-BX |
| Pressure tolerance | Less than 10 psi |
| Weight | 0.0132 lb |
| Misalignment tolerance | depends on application details |
Related products
Illustrative image
