DODGE
Call
DODGE TXT1024
#TXT1024
On request
272605
Manufacturer description272605 Shaft Mount Speed Reducer - Reducer Size: TXT1024AS, Double Reduction, 25:1 Ratio, 2.6875 in Input Shaft Size, Output Bore Type: Straight
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | DODGE |
| Category | SHAFT MOUNT SPEED REDUCERS |
| Reduction | Double |
| Housing material | Cast Iron |
| Nominal ratio | 24.3:1 |
| Housing length | 17.76 in |
| Housing width | 12.37 in |
| Drive type | Torque-Arm |
| Housing height | 35 in |
| Input type | Solid Shaft |
| Maximum input horsepower | 216.000 hp @ 75 rpm |
| Input size | 2.6875 in |
| Standards met | AGMA |
| Output bore type | Straight |
| Includes | Torque Arm |
| Manufacturer reducer size | TXT1024AS |
| Manufacturer catalog number | 272605 |
| Maximum output size | 5-7/16 in |
| Manufacturer upc number | 782475000000 |
