FAG (SCHAEFFLER) NNU4926S.M.SP
#NNU4926S.M.SP
On request
NNU4926-S-M-SP
Manufacturer descriptionCylindrical Roller Bearing - Straight, 130 mm ID, 180 mm OD, 50 mm Width, C0 Internal Clearance
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | FAG (SCHAEFFLER) |
| Category | CYLINDRICAL ROLLER BEARINGS |
| Bore diameter | 130 mm |
| Precision rating | Not Rated |
| Outside diameter | 180 mm |
| Maximum rpm | 4800 RPM |
| Overall width | 50 mm |
| Cage material | Brass |
| Flanges | (3) Outer Ring |
| Finish/coating | Uncoated |
| Bore type | Straight |
| Closure type | Open |
| Number of rows | 2 |
| Outer ring width | 50 mm |
| Internal clearance | C0 |
| Fillet radius | 1.5 mm |
| Dynamic load capacity | 190 kN |
| Series | NNU49 |
| Static load capacity | 390 kN |
