GARLOCK 24899-0135

Name: GARLOCK 24899-0135
Brand: GARLOCK
SKU: 24899-0135

#24899-0135 On request

Brand GARLOCK

Category BEARING ISOLATORS

Part Number 24899-0135

Klozure® EQUALIZER® Bearing Isolator - 1.2500 in Shaft Diameter, 1.750 in OD, 0.6250 in Wide, Labyrinth Lip

Price on request — a consultant will confirm lead time and terms.

Talk to a technical consultant

GARLOCK — GARLOCK 24899-0135

The KLOZURE® EQUALIZER® bearing isolators offer excellent bearing protection for pumps, motors, and bearing supported industrial equipment under the harshest conditions.
Special vertical top design for shafts that is in vertical position.
Mineral Filled PTFE (white) material provides excellent chemical resistance and is FDA compliant
Non-wearing components
Engineered labyrinth design excludes contamination while retaining bearing lubrication

Brand	GARLOCK
Category	BEARING ISOLATORS
Shaft diameter	1.25 in
Harmonization code	3926904590.US
Lip material	Labyrinth
Weight	0.16 lb
Construction description	EQUALIZER® Special Vertical Design, Mineral Filled PTFE Rotor and Stator and FKM O-Rings, 0.375 Flange, 1 O-Rings on OD "
Outside diameter	1.75 in
Continuous temperature range	-22°F to 400°F
Width	0.625 in
Maximum shaft surface speed	4500 FPM
Unitizing ring material	None
Misalignment tolerance	0.015 in
Rotor/stator material	Mineral Filled PTFE
Pressure tolerance	Ambient
O-ring material	FKM
Synonym	Bearing Isolator, Labyrinth, Non-contact, Energy Efficient, Non-sparking, Barrier, Rotating, Dynamic, Bearing Lubrication Retention, Contamination Exclusion Seal for Oil or Grease
Axial movement	0.015 in
Typical application	Exceptional Bearing Protection, Rotating Applications, Pumps, Gearboxes, Motors, Energy Efficient Applications, Primary Metals Industry, Steel Industry, Aluminum Industry, Pulp and Paper Industry, Chemical Industry, Food and Pharmaceutical Industry, Hydroelectric Industry, Power Generation Industry, Wind Turbine Industry, Oil and Gas Industry, Mining Industry, other Industrial Applications
Manufacturer upc number	718000000000
Type series	EQUALIZER®
