HUB CITY INC 0230-37123
#0230-37123
On request
4501 100/1 WR Single Output Right Angle Worm Gear Speed Reducer - Double Reduction, 100:1 Ratio, 4.50 in Center Distance, Solid Shaft, 0.8750 in Input Size
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
HUB CITY INC — HUB CITY INC 0230-37123
- Modular Design
- Universal Mounting Dimensions
- Increased thermal capacity and Increased efficiency
- Cast iron housing
- Viton Seals
Specifications
| Brand | HUB CITY INC |
| Category | RIGHT ANGLE WORM GEAR SPEED REDUCERS |
| Reduction | Double |
| Housing material | Cast Iron |
| Center distance | 4.5 in |
| Service factor | 1.0 |
| Maximum input horsepower | 5.580 @ 1750 hp, rpm |
| Manufacturer catalog | http://www.hubcityinc.com/documents/8B-MCC17010E10075EHubCityWormSpeedReducers.pdf#page=30 |
| Ratio | 100:1 |
| Cad drawing | http://hubcity-ps.com/psconfig/tab/index.html?0 |
| Manufacturer reducer size | 4501 |
| Manufacturer catalog number | 0230-37123 |
| Input type | Solid Shaft |
| Manufacturer upc number | 662798991351 |
| Input size | 0.875 in |
| Shipping dimensions height | 18-1/4 in |
| Output type | Solid Shaft |
| Shipping dimensions length | 20 in |
| Output size | 1.625 in |
| Shipping dimensions width | 16-5/8 in |
| Maximum output rpm | 17.5 rpm |
| Weight | 172 lbs |
| Maximum output torque | 13010 @ 17.5 output in-lbs, , rpm |
