On request
HUB CITY INC
Call
HUB CITY INC 0230-15218
#0230-15218
On request
326 25/1 L WR 182TC 1.438 Right Angle Worm Gear Speed Reducer - Single Reduction, 25:1 Ratio, 3.25 in Center Distance, C-Face Quill, 1.1250 in Input Size, 182TC Frame
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
HUB CITY INC — HUB CITY INC 0230-15218
- Modular Design
- Universal Mounting Dimensions
- Increased thermal capacity and Increased efficiency
- Cast Iron Housing
- Alloy Shafting
Specifications
| Brand | HUB CITY INC |
| Category | RIGHT ANGLE WORM GEAR SPEED REDUCERS |
| Reduction | Single |
| Maximum output rpm | 70 rpm |
| Center distance | 3.25 in |
| Maximum output torque | 2805 in-lbs |
| Maximum input horsepower | 3.920 @ 1750 hp, rpm |
| Service factor | 1.0 |
| Ratio | 25:1 |
| Manufacturer catalog | http://www.hubcityinc.com/documents/8B-MCC17010E10075EHubCityWormSpeedReducers.pdf#page=42 |
| Manufacturer reducer size | 326 |
| Cad drawing | http://hubcity-ps.com/psconfig/tab/index.html?prj=worm_gear_drives/single_reduct_wgd_pcx/series320_pcx/326_pcx_asmtab.prj&values=MN=326 |
| Input type | C-Face Quill |
| Manufacturer catalog number | 0230-15218 |
| Input size | 1.125 in |
| Manufacturer upc number | 662798973258 |
| Output type | Hollow Bore |
| Shipping dimensions height | 13-1/2 in |
| Output size | 1.4375 in |
| Shipping dimensions length | 14 in |
| Style | L |
| Shipping dimensions width | 12-1/4 in |
| Nema / iec frame size | 182TC |
| Weight | 74 lbs |
