On request
HUB CITY INC
Call
HUB CITY INC 0230-37451
#0230-37451
On request
4506 750/1 WR 143TC STD. Side Mount Right Angle Worm Gear Speed Reducer - Double Reduction, 750:1 Ratio, 4.50 in Center Distance, C-Face Quill, 0.8750 in Input Size, 143TC Frame
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
HUB CITY INC — HUB CITY INC 0230-37451
- Modular Design
- Universal Mounting Dimensions
- Increased thermal capacity and Increased efficiency
- Cast iron housing
- Viton Seals
Specifications
| Brand | HUB CITY INC |
| Category | RIGHT ANGLE WORM GEAR SPEED REDUCERS |
| Reduction | Double |
| Maximum output torque | 15480 @ 2.33 output in-lbs, , rpm |
| Center distance | 4.5 in |
| Housing material | Cast Iron |
| Maximum input horsepower | 1.320 @ 1750 hp, rpm |
| Service factor | 1.0 |
| Ratio | 750:1 |
| Manufacturer catalog | http://www.hubcityinc.com/documents/8B-MCC17010E10075EHubCityWormSpeedReducers.pdf#page=30 |
| Manufacturer reducer size | 4506 |
| Cad drawing | http://hubcity-ps.com/psconfig/tab/index.html?0 |
| Input type | C-Face Quill |
| Manufacturer catalog number | 0230-37451 |
| Input size | 0.875 in |
| Manufacturer upc number | 662798991955 |
| Output type | Hollow Bore |
| Shipping dimensions height | 30 in |
| Output size | BUSHING KIT REQ'D |
| Shipping dimensions length | 48 in |
| Nema / iec frame size | 143TC |
| Shipping dimensions width | 24 in |
| Maximum output rpm | 2.33 rpm |
| Weight | 189 lbs |
