HUB CITY INC
Call
HUB CITY INC 0230-14616
#0230-14616
On request
321 15/1 B WR Right Angle Worm Gear Speed Reducer - Single Reduction, 15:1 Ratio, 3.25 in Center Distance, Solid Shaft, 0.8750 in Input Size
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
HUB CITY INC — HUB CITY INC 0230-14616
- Modular Design
- Universal Mounting Dimensions
- Increased thermal capacity and Increased efficiency
- Cast Iron Housing
- Alloy Shafting
Specifications
| Brand | HUB CITY INC |
| Category | RIGHT ANGLE WORM GEAR SPEED REDUCERS |
| Reduction | Single |
| Maximum output torque | 2498 in-lbs |
| Center distance | 3.25 in |
| Service factor | 1.0 |
| Maximum input horsepower | 5.570 @ 1750 hp, rpm |
| Manufacturer catalog | http://www.hubcityinc.com/documents/8B-MCC17010E10075EHubCityWormSpeedReducers.pdf#page=30 |
| Ratio | 15:1 |
| Cad drawing | http://hubcity-ps.com/psconfig/tab/index.html?prj=worm_gear_drives/single_reduct_wgd_pcx/series320_pcx/321_pcx_asmtab.prj&values=MN=321 |
| Manufacturer reducer size | 321 |
| Manufacturer catalog number | 0230-14616 |
| Input type | Solid Shaft |
| Manufacturer upc number | 662798967264 |
| Input size | 0.875 in |
| Shipping dimensions height | 11 in |
| Output type | Solid Shaft |
| Shipping dimensions length | 12 in |
| Output size | 1.375 in |
| Shipping dimensions width | 10 in |
| Style | B |
| Weight | 60 lbs |
| Maximum output rpm | 117 rpm |
