HUB CITY INC
Call
HUB CITY INC 0230-24320
#0230-24320
On request
2604 3600/1 WR 56C Single Output Right Angle Worm Gear Speed Reducer - Double Reduction, 3600:1 Ratio, 2.62 in Center Distance, C-Face Quill, 0.6250 in Input Size, 56C Frame
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
HUB CITY INC — HUB CITY INC 0230-24320
- Modular Design
- Universal Mounting Dimensions
- Increased thermal capacity and Increased efficiency
- Cast iron housing
- Viton® Seals
Specifications
| Brand | HUB CITY INC |
| Category | RIGHT ANGLE WORM GEAR SPEED REDUCERS |
| Reduction | Double |
| Maximum output torque | 2261 @ 0.49 output in-lbs, , rpm |
| Center distance | 2.62 in |
| Housing material | Cast Iron |
| Maximum input horsepower | 0.072 @ 1750 hp, rpm |
| Service factor | 1.0 |
| Ratio | 3600:1 |
| Manufacturer catalog | http://www.hubcityinc.com/documents/8B-MCC17010E10075EHubCityWormSpeedReducers.pdf#page=30 |
| Manufacturer reducer size | 2604 |
| Cad drawing | http://hubcity-ps.com/psconfig/tab/index.html?prj=worm_gear_drives/double_reduct_wgd_pcx/series2600_pcx/2604_pcx_asmtab.prj&values=MN=2604 |
| Input type | C-Face Quill |
| Manufacturer catalog number | 0230-24320 |
| Input size | 0.625 in |
| Manufacturer upc number | 662798995830 |
| Output type | Solid Shaft |
| Shipping dimensions height | 13-1/2 in |
| Output size | 1.25 in |
| Shipping dimensions length | 14 in |
| Nema / iec frame size | 56C |
| Shipping dimensions width | 12-1/4 in |
| Maximum output rpm | 0.49 rpm |
| Weight | 48 lbs |
