On request
HUB CITY INC
Call
HUB CITY INC 0230-20307
#0230-20307
On request
2106 300/1 WR 56C 1.000 Side Mount Right Angle Worm Gear Speed Reducer - Double Reduction, 300:1 Ratio, 2.06 in Center Distance, C-Face Quill, 0.6250 in Input Size, 56C Frame
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
HUB CITY INC — HUB CITY INC 0230-20307
- Modular Design
- Universal Mounting Dimensions
- Increased thermal capacity and Increased efficiency
- Cast iron housing
- Viton® Seals
Specifications
| Brand | HUB CITY INC |
| Category | RIGHT ANGLE WORM GEAR SPEED REDUCERS |
| Reduction | Double |
| Maximum output torque | 1211 @ 5.83 output in-lbs, , rpm |
| Center distance | 2.06 in |
| Housing material | Cast Iron |
| Maximum input horsepower | 0.212 @ 1750 hp, rpm |
| Service factor | 1.0 |
| Ratio | 300:1 |
| Manufacturer catalog | http://www.hubcityinc.com/documents/8B-MCC17010E10075EHubCityWormSpeedReducers.pdf#page=30 |
| Manufacturer reducer size | 2106 |
| Cad drawing | http://hubcity-ps.com/psconfig/tab/index.html?prj=worm_gear_drives/single_reduct_wgd_pcx/series_w420_pcx/w426l_pcx_asmtab.prj&values=MN=426L |
| Input type | C-Face Quill |
| Manufacturer catalog number | 0230-20307 |
| Input size | 0.625 in |
| Manufacturer upc number | 662798988436 |
| Output type | Hollow Bore |
| Shipping dimensions height | 7-1/2 in |
| Output size | 1 in |
| Shipping dimensions length | 13-1/4 in |
| Nema / iec frame size | 56C |
| Shipping dimensions width | 12-1/2 in |
| Maximum output rpm | 5.83 rpm |
| Weight | 41 lbs |
