INA (SCHAEFFLER) HK1210-AS1
#HK1210-AS1
On request
HK1210-AS1-B
Manufacturer descriptionDrawn Cup Needle Roller Bearing - Open Ends, 12 mm Bore, 16 mm OD, 10 mm Width
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | INA (SCHAEFFLER) |
| Category | DRAWN CUP NEEDLE ROLLER BEARINGS |
| Bore diameter | 12 mm |
| Static load capacity | 1390 lbf |
| Outside diameter | 16 mm |
| Cage material | Steel |
| Overall width | 10 mm |
| Maximum rpm | 20000 RPM |
| Drawn cup type | Open Ends |
| Precision rating | Not Rated |
| Closure type | Open |
| Series | HK |
| Number of rows | One |
| Lubrication hole type | Lubrication Hole |
| Operating temperature range | Maximum of +140 °C |
| Standards met | DIN 618-1/ISO 3245 |
| Dynamic load capacity | 1110 lbf |
| Compatible inner ring | IR 8x12x10.5 |
