MARATHON ELECTRIC R317
#R317
On request
100LTFC6586 General Purpose Motor - 3 ph, 1-1/2 hp, 1200 rpm, 230/460 V, 100L Frame, TEFC (Totally Enclosed Fan Cooled) Enclosure, 60 Hz, Rigid Base Mount, 1185 rpm Base RPM
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
MARATHON ELECTRIC — MARATHON ELECTRIC R317
- Meets IE3 European and NEMA Premium® efficiencies
- Aluminum (63-90 frame) or Cast Iron (100-315 frame) frame construction
- Nameplated 60/50 hertz at same HP, above 90 frame is 60/50 Hz at next lower HP
- MAX GUARD® Class F Insulation, Class B rise @ rated KW
- IP55 weatherproof enclosure, Rotatable/Removable Base (63-90 frame)
Specifications
| Brand | MARATHON ELECTRIC |
| Category | GENERAL PURPOSE MOTORS |
| Motor phase | 3 ph |
| Shaft type | IEC |
| Motor horsepower | 1-1/2 hp |
| Ambient temperature range | 40 °C |
| Synchronous rpm | 1200 rpm |
| Bearing type | Ball Bearing |
| Motor supply voltage | 230/460 V |
| Opposite drive end bearing type | Ball |
| Frame size | 100L |
| Service factor | 1.15 |
| Enclosure type | TEFC (Totally Enclosed Fan Cooled) |
| Frame material | Cast Iron |
| Frequency rating | 60 Hz |
| Insulation class | F |
| Mounting type | Rigid Base |
| Ip rating | 55 |
| Base rpm | 1185 rpm |
| Standards met | CE,UL Recognized |
| Assembly/box mounting | F3 |
| Motor design code | B |
| Duty / condition type | Continuous Duty |
| Drive end bearing size | 6206 |
| Full load current | 4.60 / 2.30 A |
| Substitute motor | TCA1P13AE211GAA009 |
| Electrical type | Squirrel Cage Inverter Rated |
| Opposite drive end bearing size | 6205 |
| Full load efficiency | 0.875 |
| Overload protector | No Overload Protector |
| Kva code | K |
| Weight | 90 lbs |
| Kw | 1.1 kW |
| Manufacturer upc number | 722856026316 |
| Motor orientation | Horizontal |
| Motor poles | 6 |
| Storage dimension height | 16.81 in |
| Number of speeds | 1 |
| Storage dimension width | 22.5 in |
| Starting method | Line Or Inverter |
| Storage dimension length | 14 in |
| Shaft diameter | 1.111 in |
| Shaft rotation | Reversible |
