SMC VQZ335-9L-03T(AC24V)
#VQZ335-9L-03T(AC24V)
On request
Solenoid-Operated Air Control Valve - Base Mounted Subplate Included, 3 Port, 2 Position, Single Solenoid
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | SMC |
| Category | SOLENOID-OPERATED AIR CONTROL VALVES |
| Number of ports | 3 |
| Operating temperature range | 14 to 122 °F |
| Piping type | Base Mounted Subplate Included |
| Maximum operating pressure | 145 psi |
| Number of positions | 2 |
| Seal material | Rubber |
| Number of solenoids | Single |
| Operating medium | Air, Inert Gas |
| Solenoid supply voltage | 24 V ac |
| Flow direction | 2-Way |
| Solenoid supply frequency | 50/60 Hz |
| Normal state | Normally Closed |
| Solenoid electrical entry | L Plug |
| Port size | 3/8 NPTF |
| Flow coefficient (cv) / flow factor (kv) | 1 (A to R) , 1.3 (P to A) Cv |
| Standards met | JIS, JIS B 8375-1981, IEC 60529 |
| Manual operation type | Non-Locking Push |
