On request
SPHERCO (RBC BEARINGS)
Call
SPHERCO (RBC BEARINGS) TRL6N
#TRL6N
On request
TRL 6 N ROD END
Manufacturer descriptionSpherco® Spherical Rod End - Grade: Precision, Bore Diameter: 0.3750 in, Shank Thread Size: 3/8-24, Lubricatable
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | SPHERCO (RBC BEARINGS) |
| Category | SPHERICAL ROD ENDS |
| Bore diameter | 0.375 in |
| Radial static load capacity | 4450 lbf |
| Misalignment angle | 6 º |
| Maximum operating temperature | 250 ºF |
| Shank thread length | 0.937 in |
| Head diameter | 1 in |
| Rod end type | Female Threaded |
| Head width | 0.406 in |
| Shank thread size | 3/8-24 |
| Ball diameter | 0.718 in |
| Thread direction | Left Hand |
| Ball width | 0.5 in |
| Grade | Precision |
| Length to ball center | 1.625 in |
| Thread type | UNF-3B |
| Overall height | 2.125 in |
| Lubrication type | Lubricatable |
| Series | TRL Series 4 Piece-Metal-to-Metal |
| Housing material | Carbon Steel |
| Manufacturer upc number | 637400189419 |
| Ball material | 52100 Alloy Steel |
| Weight | 0.12 lbs |
| Race material | Brass |
