SPHERCO (RBC BEARINGS)
Call
SPHERCO (RBC BEARINGS) TRE3Y
#TRE3Y
On request
TRE 3Y ROD END
Manufacturer descriptionSpherco® Spherical Rod End - Grade: Precision, Bore Diameter: 0.1900 in, Shank Thread Size: .1900-32, Non-Lubricatable
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | SPHERCO (RBC BEARINGS) |
| Category | SPHERICAL ROD ENDS |
| Bore diameter | 0.19 in |
| Radial static load capacity | 900 lbf |
| Misalignment angle | 6.5 º |
| Maximum operating temperature | 250 ºF |
| Shank thread length | 0.75 in |
| Head diameter | 0.625 in |
| Rod end type | Male Threaded with Male Stud |
| Head width | 0.25 in |
| Shank thread size | .1900-32 |
| Ball diameter | 0.437 in |
| Thread direction | Right Hand |
| Ball width | 0.312 in |
| Grade | Precision |
| Length to ball center | 1.25 in |
| Thread type | UNF-3A |
| Overall height | 1.5625 in |
| Lubrication type | Non-Lubricatable |
| Series | TRE Series 4 Piece-Metal-to-Metal |
| Housing material | Carbon Steel |
| Manufacturer upc number | 637400188139 |
| Ball material | 52100 Alloy Steel |
| Weight | 0.03 lbs |
| Race material | Brass |
