On request
SPHERCO (RBC BEARINGS)
Call
SPHERCO (RBC BEARINGS) TRE4YN
#TRE4YN
On request
TRE4YN ROD END
Manufacturer descriptionSpherco® Spherical Rod End - Grade: Precision, Bore Diameter: 0.2500 in, Shank Thread Size: 1/4-28, Lubricatable
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | SPHERCO (RBC BEARINGS) |
| Category | SPHERICAL ROD ENDS |
| Bore diameter | 0.25 in |
| Maximum operating temperature | 250 ºF |
| Misalignment angle | 8 º |
| Operating temperature range | Max 250 °F |
| Shank thread length | 1 in |
| Head diameter | 0.75 in |
| Rod end type | Male Threaded with Male Stud |
| Head width | 0.281 in |
| Shank thread size | 1/4-28 |
| Ball diameter | 0.515 in |
| Thread direction | Right Hand |
| Ball width | 0.375 in |
| Grade | Precision |
| Length to ball center | 1.562 in |
| Thread type | UNF-3A |
| Overall height | 1.937 in |
| Lubrication type | Lubricatable |
| Series | TRE Series 4 Piece-Metal-to-Metal |
| Housing material | Carbon Steel |
| Manufacturer product page | http://rbcbearings.stage.thomasnet-navigator.com/item/all-categories/d-bearing-series-tre-female-4-piece-metal-to-metal/tre4yn |
| Ball material | 52100 Alloy Steel |
| Manufacturer upc number | 637400188269 |
| Race material | Brass |
| Weight | 0.05 lbs |
| Radial static load capacity | 1700 lbf |
Related products
Illustrative image
