SPHERCO (RBC BEARINGS) CFF3Y
#CFF3Y
On request
CFF3Y ROD END
Manufacturer descriptionSpherco® Spherical Rod End - Grade: Commercial, Bore Diameter: 0.1900 in, Shank Thread Size: .1900-32, Non-Lubricatable
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | SPHERCO (RBC BEARINGS) |
| Category | SPHERICAL ROD ENDS |
| Bore diameter | 0.19 in |
| Radial static load capacity | 2000 lbf |
| Misalignment angle | 6.5 º |
| Maximum operating temperature | 250 ºF |
| Shank thread length | 0.562 in |
| Operating temperature range | Max 250 °F |
| Rod end type | Female Threaded with Male Stud |
| Head diameter | 0.625 in |
| Shank thread size | .1900-32 |
| Head width | 0.25 in |
| Thread direction | Right Hand |
| Ball diameter | 0.437 in |
| Grade | Commercial |
| Ball width | 0.312 in |
| Thread type | UNF-3B |
| Length to ball center | 1.062 in |
| Lubrication type | Non-Lubricatable |
| Overall height | 1.375 in |
| Housing material | Carbon Steel |
| Series | CFF Series 2 Piece - Metal-to-Metal |
| Ball material | 52100 Alloy Steel |
| Manufacturer product page | http://rbcbearings.stage.thomasnet-navigator.com/item/all-categories/d-bearing-series-cff-female-2-piece-metal-to-metal/cff3y |
| Finish/coating | Steel |
| Manufacturer upc number | 637400191559 |
| Race material | Steel |
| Weight | 0.03 lbs |
