SPHERCO (RBC BEARINGS) TR3Y

Name: SPHERCO (RBC BEARINGS) TR3Y
Brand: SPHERCO (RBC BEARINGS)
SKU: TR3Y

#TR3Y On request

Category SPHERICAL ROD ENDS

Part Number TR3Y

TR3Y ROD END

Manufacturer description

Spherco® Spherical Rod End - Grade: Precision, Bore Diameter: 0.1900 in, Shank Thread Size: .1900-32, Non-Lubricatable

Price on request — a consultant will confirm lead time and terms.

Talk to a technical consultant

Specifications

Brand	SPHERCO (RBC BEARINGS)
Category	SPHERICAL ROD ENDS
Bore diameter	0.19 in
Maximum operating temperature	250 ºF
Misalignment angle	6.5 º
Operating temperature range	Max 250 °F
Shank thread length	0.562 in
Head diameter	0.625 in
Rod end type	Female Threaded with Male Stud
Head width	0.25 in
Shank thread size	.1900-32
Ball diameter	0.437 in
Thread direction	Right Hand
Ball width	0.312 in
Grade	Precision
Length to ball center	1.062 in
Thread type	UNF-3B
Overall height	1.375 in
Lubrication type	Non-Lubricatable
Series	TR Series 4 Piece-Metal-to-Metal
Housing material	Carbon Steel
Manufacturer product page	http://rbcbearings.stage.thomasnet-navigator.com/item/all-categories/-end-bearing-series-tr-male-4-piece-metal-to-metal/tr3y
Ball material	52100 Alloy Steel
Manufacturer upc number	637400190446
Race material	Brass
Weight	0.03 lbs
Radial static load capacity	1850 lbf
