TB WOODS (ALTRA)
Call
TB WOODS (ALTRA) 11SCHS158
#11SCHS158
On request
11SC-HS X 1-5/8 SPACER HUB
Manufacturer descriptionSleeve Coupling Hub - Size 11, 1-5/8 in Bore, Finished with Keyway, Cast Iron
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | TB WOODS (ALTRA) |
| Category | SLEEVE COUPLING HUBS |
| Bore diameter | 1-5/8 in |
| Hub end outside diameter | 5-1/4 in |
| Flange diameter | 8-5/8 in |
| Distance between shafts | 5 , 7 , 7-3/4 , 4-3/4 in |
| Length through bore | 2-23/32 in |
| Torque capacity | 18000 in·lb |
| Coupling size code | 11 |
| Maximum rpm | 3600 RPM |
| Bore type | Finished w/ Keyway |
| Horsepower @ 100 rpm | 7.2 (EPDM & Neoprene) , 28.6 (Hytrel & Urethane) hp |
| Hub type | Shaft Hub |
| Series | Sure-Flex |
| Hub flange type code | SCH |
| Keyway size | 3/8 x 3/16 in |
| Hub material | Cast Iron |
| Manufacturer product page | http://ecatalog.tbwoods.com/ecatalog/sureflex_couplings/en/11SCHS158 |
| Coupling overall length | 10-3/8 , 12-3/8 , 13-1/8 , 10-5/16 in |
