TB WOODS (ALTRA)
Call
TB WOODS (ALTRA) 9S30MM
#9S30MM
On request
9S X 30MM SURE-FLEX FLANGE
Manufacturer description9S30MM Sleeve Coupling Flange - Shaft Hub, Size 9, 30 mm Bore, Cast Iron
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | TB WOODS (ALTRA) |
| Category | SLEEVE COUPLING FLANGES |
| Bore diameter | 30 mm |
| Coupling overall length | 5.0625 in |
| Flange diameter | 6.35 in |
| Hub end outside diameter | 3.625 in |
| Length through bore | 2.4063 in |
| Maximum rpm | 3750 RPM |
| Hub flange type code | S |
| Horsepower @ 100 rpm | 3.7 HP with EPDM or Neoprene , 11 HP with Hytrel sleeve |
| Coupling size code | 9 |
| Series | Sure-Flex |
| Bore type | Finish with Keyway |
| Keyway size | 8 x 3.3 mm |
| Hub type | Shaft Hub |
| Manufacturer upc number | 698673000000 |
| Hub material | Cast Iron |
