TIMKEN (FAFNIR)
Call
TIMKEN (FAFNIR) LCJ1
#LCJ1
On request
Flange-Mount Ball Bearing Unit - Four-Bolt Flange, 1.0000 in Bore, Cast Iron Housing, Standard Duty, Eccentric Collar Locking, Labyrinth
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | TIMKEN (FAFNIR) |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 1 in |
| Radial static load capacity | 1730 lb |
| Bolt center-to-center length | 2.75 in |
| Seal type | Labyrinth |
| Overall length/diameter | 3.75 in |
| Length through bore | 46.6 mm |
| Bore type | Round |
| Finish/coating | Uncoated |
| Duty type | Standard Duty |
| Maximum rpm | 9070 RPM |
| Mounting type | Four-Bolt Flange |
| Lubrication type | Cannot Be Relubricated |
| Housing material | Cast Iron |
| Series | LCJ |
| Locking device | Eccentric Collar |
| Standards met | FDA Compliant, USDA Compliant |
| Expansion type | Non-Expansion Bearing (Fixed) |
| Replacement bearing | G1100KLLB |
| Radial dynamic load capacity | 3550 lb |
