TIMKEN (FAFNIR)
Call
TIMKEN (FAFNIR) G1200KRRB
#G1200KRRB
On request
Ball Insert Bearing - Round Bore, 2.0000 in ID, 3.9370 in OD, 2.1875 in Width
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
TIMKEN (FAFNIR) — TIMKEN (FAFNIR) G1200KRRB
- The G-KRRB Series wide inner ring bearings are the same as RRB Series and have a provision for relubrication
- Designed for extremely dirty or wet conditions
- Includes R-Seals with flared lips that firmly contact the ground OD of the inner ring. The inner ring provides a positive seal against dust, dirt and other contaminants and effectively retains the lubricant
- G-KRRB Series bearings are equipped with Shroud-Seals, providing extra effectiveness and protection
- Extra-wide design provides additional shaft and extra-large grease capacity
Specifications
| Brand | TIMKEN (FAFNIR) |
| Category | BALL INSERT BEARINGS |
| Bore diameter | 2 in |
| Cage material | Nylon |
| Outside diameter | 3.937 in |
| Snap ring included | Without Snap Ring |
| Outer ring width | 24 mm |
| Finish/coating | Uncoated |
| Inner ring width | 2.1875 in |
| Maximum rpm | 2260 RPM |
| Bore type | Round |
| Series | G-KRRB |
| Overall width | 2.1875 in |
