VICKERS (EATON) DG5V-7-6C-M-U-B5-40

Name: VICKERS (EATON) DG5V-7-6C-M-U-B5-40
Brand: VICKERS (EATON)
SKU: DG5V-7-6C-M-U-B5-40

#DG5V-7-6C-M-U-B5-40 On request

Category HYDRAULIC DIRECTIONAL CONTROL VALVES

Part Number DG5V-7-6C-M-U-B5-40

02-352817

Manufacturer description

02-352817 Directional Control Valve - Pilot Actuation, 4-Way, D07 Valve, 80 gpm Max Flow, 110 V ac (50 Hz) / 120 V ac (60 Hz) Coil

Price on request — a consultant will confirm lead time and terms.

Talk to a technical consultant

Specifications

Brand	VICKERS (EATON)
Category	HYDRAULIC DIRECTIONAL CONTROL VALVES
Actuation type	Pilot
Design number	40
Valve size	D07
T port pressure rating	3045 psi
Maximum flow rate	80 gpm
Valve application	Industrial
Maximum operating pressure	5000 psi
Maximum ambient temperature	150 °F
Coil voltage	110 V ac (50 / 120 V ac (60 Hz)
Maximum operating temperature	158 °F
Spool type	Closed Center (P Blocked, A & B to T)
Minimum operating temperature	-4 °F
Spool/spring arrangement	Spring Centered
Overall height	182 mm
Mounting type	Subplate
Overall width	95.2 mm
Flow direction	4-Way
Overall length	200 mm
Electrical connection	ISO 4400 (DIN 43650) Mounting
