On request
VICKERS (EATON)
Call
VICKERS (EATON) DG5V-10-A-8C-2-E-VM-B-10
#DG5V-10-A-8C-2-E-VM-B-10
On request
Brand
VICKERS (EATON)
Category
HYDRAULIC DIRECTIONAL CONTROL VALVES
Part Number
DG5V-10-A-8C-2-E-VM-B-10
02-321652
Manufacturer description02-321652 Directional Control Valve - Pilot Actuation, 4-Way, D10 Valve, 290 gpm Max Flow, 110 V ac (50 Hz) / 120 V ac (60 Hz) Coil
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | VICKERS (EATON) |
| Category | HYDRAULIC DIRECTIONAL CONTROL VALVES |
| Actuation type | Pilot |
| Design number | 10 |
| Valve size | D10 |
| T port pressure rating | 3045 psi |
| Maximum flow rate | 290 gpm |
| Valve application | Industrial |
| Maximum operating pressure | 5000 psi |
| Maximum operating temperature | 150 °F |
| Coil voltage | 110 V ac (50 / 120 V ac (60 Hz) |
| Seal material | Nitrile |
| Spool type | Tandem Center (P to T) Open Crossover |
| Spool/spring arrangement | Spring Centered |
| Overall height | 364.5 mm |
| Mounting type | Subplate |
| Overall width | 196.8 mm |
| Flow direction | 4-Way |
| Overall length | 541 mm |
