WEG ELECTRIC CORPORATION 12518ET3G444TC-W22
#12518ET3G444TC-W22
On request
General Purpose Motor - 3 ph, 125 hp, 1800 rpm, 460 V, 444/5TC Frame, TEFC (Totally Enclosed Fan Cooled) Enclosure, 60 Hz, Footed/C-Face Flange Mount
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | WEG ELECTRIC CORPORATION |
| Category | GENERAL PURPOSE MOTORS |
| Motor phase | 3 ph |
| Volts @ frequency | 460 @ 60 V, Hz |
| Motor horsepower | 125 hp |
| Overall length (c-dimension) | 44.95 in |
| Synchronous rpm | 1800 rpm |
| Service factor | 1.15 |
| Motor supply voltage | 460 V |
| Frame material | Cast Iron |
| Frame size | 444/5TC |
| Insulation class | F |
| Enclosure type | TEFC (Totally Enclosed Fan Cooled) |
| Ip rating | 55 |
| Frequency rating | 60 Hz |
| Standards met | UL, CSA, CE |
| Mounting type | Footed/C-Face Flange |
| Weight | 1754 lbs |
| Duty / condition type | Continuous Duty |
| Harmonization code | 8501.53.4080 |
| Full load current | 139.00 A |
| Full load efficiency | 0.954 |
